Main Technical Variables:
|
Model
|
ZIP-55
|
ZIP-65
|
|
Material
|
LDPE
|
LDPE
|
|
Extruding output
|
5-25kg
|
10-30kg
|
|
Film width
|
50-480mm
|
100-580mm
|
|
Thickness of film
|
0.04-0.15mm
|
0.04-0.15mm
|
|
Film annulus diameter
|
Φ550mm
|
Φ550mm
|
|
Diameter of screw
|
Φ55mm
|
Φ65mm
|
|
Draw Ratio of Screw
|
28:1
|
28:1
|
|
Heater
|
12kw
|
15kw
|
|
Power
|
25kw
|
30kw
|
|
Outline dimension(L*W*H)
|
6000*1200*4100mm
|
6000*1200*4100mm
|
If you have any enquiry about quotation or cooperation,please feel free to email us at ray@sanbi.comor use the following enquiry form. Our sales representative will contact you soon. Thank you for your interest in our products.
