This machine is suitable for regeneration and granulation of waste plastics,as HDPE,LDPE,and PP,etc.
It is equipped with quick motor-operated filter-screen-replacing unit and automatic temperature control.
The granulating crusher uses adjustable speed motor,pelleting with an extruding machine at the same discharging speed synchronistically.
The unit is easy to operate,with a high output,steady performance,and favorable economic benefit.
Main Technical Variables:
| Model | SJ-90 | SJ-100 | SJ-110 | SJ-120 |
| Type Diameter of Screw Stem | φ90 | φ100 | φ110 | φ120 |
| Major Diameter Ratio of Screw Stem | L/D 20:1 -22:1 | L/D 20:1 -22:1 | L/D 20:1 -22:1 | L/D 20:1 -22:1 |
| Rational Speed of Screw Stem | 10-100r/min | 10-100r/min | 10-100r/min | 10-100r/min |
| Main Motor Power | 22kw | 30kw | 37kw | 45kw |
| Output | 68kg/h | 95kg/h | 120kg/h | 135kg/h |
| Weight of overall(kg) | 2600kg | 2800kg | 3000kg | 3200kg |
| Cover dimensions (l*w*h) (mm) | 4000*1500*1800 | 4000*1500*1800 | 4000*1500*1800 | 4000*1500*1800 |
